TC Helicon VoiceTone C1 Hard-Tune and Correction Vocal FX Pedal

With HardTune effects, subtle pitch correction & gender manipulation, VoiceTone C1 opens up new vocal territory on stage!

VoiceTone C1 has clean, transparent pitch correction capability with unique control of musical input via the guitar input if desired. When transparency isn’t your bag, cranking the attack and gender controls will turn the C1's pitch correction into the robotic modern effect heard everywhere.

VOICETONE C1 TECH SPECS

Control

Key/Auto selection

Correction Amount

Gender Amount

Footswitch on/off

Mic Control on/off

Design

VoiceTone C1 dimensions

Size

Height: 5.4 inches (140 mm)

Width: 3.5 inches (90 mm)

Depth: 2.3 inches (60 mm)

Weight

Weight: 0.92 lb. (0.42 kg)

Construction

Two part dies cast metal

Rubberized base

Connections

Analog Inputs

Connectors, balanced: Mic.: XLR

Mic Input Level @ 0 dBFS: -42dBu to +1dBu

EIN @ Max Mic Gain Rg = 150 Ohm: -126 dBu

Mic input SNR: >104 dB

Phantom Power: 24V (always on)

Guitar Input impedance: 1 MOhm

Guitar Input Level @ 0 dBFS: -7 dBU to 17 dBu

Guitar Input SNR: >115dB

Analog Outputs

Output Impedance, Bal./Unbal.: 200/100 Ohm

Output Full Scale: +1 dBu

Dynamic Range: >104 dB, 20 Hz to 20 kHz

Frequency Response: +0/-0.3 dB, 20 Hz to 20 kHz

Control

USB for firmware and control

Mic Control using TC-Helicon MP-75

Details

Power

Power Supply (Supplied): 12V .4A

Power Consumption: 5.6W

Safety

EMC – Complies with EN 55103-1 and EN 55103-2 FCC part 15, Class B, CISPR 22, Class B

Safety – certified to IEC 65, EN 60065, UL6500 and CSA IEC 65, EN 60065, UL6500 and CSA

Operating Requirements

Operating Temperature: 32°F to 122°F (0°C to 50°C)

Storage Temperature: -22°F to 167°F (-30°C to 70°C)

Humidity: Max. 90 % non-condensing

Included with VoiceTone C1

Region specific power supply

USB cable

User guide
