MXR DD11 DIME DISTORTION PEDAL
The Dime Distortion delivers a heavy, aggressive and razor-sharp tone that rages with distortion but remains tight and focused enough to keep up with lightning-fast rhythm lines and scorching solos.
With its 3-band EQ, proprietary Scoop switch and ungodly output, this stompbox from Hell has the guts and the muscle to stand up to your heaviest displays of power. Who knows where it might take you!
• Thick, powerful distortion with superior definition
• Proprietary SCOOP switch notches mids for the heavily scooped Dime sound
• Three-band EQ provides huge tonal flexibility
• Two Year Warranty
HOW DOES IT WORK?
MXR DD11 CONTROLS
• 1) SCOOP switch cuts midrange at 1kHz by -22dB (indicated by yellow LED)
• 2) OUTPUT knob controls overall effect volume
• 3) BASS knob cuts or boosts low frequencies
• 4) MID knob cuts or boosts midrange frequencies
• 5) TREB knob cuts or boosts high frequencies
• 6) GAIN knob controls amount of distortion
• 7) FOOTSWITCH toggles effect on/ bypass (red LED indicates on)
MXR DD11 DIRECTIONS
• Run a cable from your bass to the Dime Distortion’s Input jack and run another cable from the Dime Distortion’s Output jack to your amplifier.
• Start with all controls at 12 o’clock
• Turn the effect on by depressing the footswitch
• Push the SCOOP switch to cut midrange at 1kHZ by -22dB for a scooped metal tone
• Rotate the OUTPUT clockwise to increase volume or counterclockwise to decrease it
• Rotate the DISTORTION knob clockwise to increase amount of distortion or counterclockwise to decrease it
• Rotate the BASS knob clockwise to boost low frequencies or counterclockwise to cut them
• Rotate the MID knob clockwise to boost midrange frequencies or counterclockwise to cut them
• Rotate the TREB knob clockwise to boost high frequencies or counterclockwise to cut them
• Rotate the DISTORTION knob clockwise to increase amount of distortion or counterclockwise to decrease it
• Then crank up your guitar and let the power of the Dime Distortion rage through you . . .
MXR DD11 SPECIFICATIONS
• Input Impedance: 1 MΩ
• Output Impedance: 3 kΩ
• Noise Floor: -89 dBV (All controls at mid-position, A-weighted)
• Bypass: Hardwired
• Current Draw: 14 mA
• Power Supply: 18 volts DC
MXR DD11 POWER
The MXR Dime Distortion may be powered by the following devices:
• 1 x 18-volt AC adapter such as the Dunlop ECB004/ECB004E (included)
• 2 x 9-volt batteries (accessed via bottom of pedal),
• 1 x DC Brick™ power supply
